30 MHz to 120 MHz 1645cm Whip Antenna, BNC Male connector, 7/8-20 installation screw TNC-Male
Military FT-RF Taiwan
10 out of
10
-
Description & Specification
30-120 MHz Tactical VHF Whip Antenna
Model: ME-30120G02-BM | 1645mm High-Gain | BNC/TNC-Male | MIL-STD-810
The ME-30120G02-BM is a high-performance Tactical Whip Antenna specifically engineered for mission-critical VHF communications across the 30 MHz to 120 MHz spectrum. Measuring 1645mm in length, this high-gain radiator provides superior line-of-sight range for tactical systems. Fully compliant with MIL-STD-810, it ensures unwavering signal stability and mechanical endurance in the most hostile operational environments.
Technical Specifications
Electrical & Performance
| Frequency Range | 30 - 120 MHz |
| V.S.W.R | ≤ 3.5 : 1 (Full Range) |
| Radiation Pattern | Omnidirectional |
| Impedance | 50 Ohm |
| Connector Type | BNC-Male / TNC-Male |
| Mounting Screw | 7/8-20 Installation Screw |
Mechanical & Environmental
| Total Length | 1645 mm |
| Base Dimensions | 29 x 1645 mm |
| Net Weight | 700 g |
| Military Standard | MIL-STD-810G Compliant |
| Appearance | Tactical Matte Black |
| Durability Test | Vibration 5.0G / High Impact Tested |
Key Tactical Features
High-Reach Signal Propagation
The 1645mm whip length provides a significant advantage in line-of-sight communications over compact antennas, ensuring superior Signal Integrity.
Industrial Mounting Base
Equipped with a 7/8-20 installation screw, providing a high-torque attachment point for vehicle-mounted Tactical Use.
Broadband Tactical Agility
Spans 30-120 MHz, allowing for seamless integration with modern combat net radios and emergency Signal Management systems.
MIL-STD-810 Reliability
Designed and tested to withstand intense vibrations and mechanical shocks, guaranteeing professional Signal Security in the field.
Get a Quote / Customization
Contact us for custom length modifications, alternative thread patterns, or specialized tactical connector requirements.
