XX -XXXXXX Antenna Category Antenna Frequency AM Antenna mast 130 1 Mhz to 30 MHz GK Military Antenna Gooseneck 30108 30MHz - 108MHz MH Military Handheld Manpack Antenna 05M06G 500MHz-6000MHz MJ  Vehicle Omnidirectional Continuous High Power Antenna 200500M 200MHz-500MHz ME Continuous High Power Antenna For Handheld & Manpack 1014G 1.2GHz-1.4GHz MI Antenna Springs Adapter  1214G 1.4GHz - 1.6GHz  MP High Power Panel Directional Continuous High Power Antenna 0927G08A 924-961/ 1804-1881/ 2109-2171/ 2599-2701 MHz  MT Omni Broadband antenna 1012G 1GHz-1.2GHz  MV Military Vehicle Antenna (Vehicular antennas) 25M03 25MHz-3GHz WP Whip Antenna 92406G 924-961/1804-1881/2599-2701/5500-6000 MHz DC Discone Antenna     HL Horn Antenna     MG Military GPS     MT Military Tactical & Base station Antenna     FT-7500 Military HF Marine Antenna     IP Military Log periodic antenna     RH RHCP Helical     RL LHCP Helical     RQ RHCP Quadrifilar Helix     LS Fin Shaped Antenna     LQ LHCP Quadrifilar Helix

FT-7500 | MF-HF Self-Supporting Antenna   The FT-7500 is the star of FT-Military RF's product line, specifically engineered for the HF frequency range (1 to 30 MHz). Its design and specialized coating are optimized for superior performance in various marine and water environments. Frequency Range: Covers 1.5 to 30 MHz (MF-HF band) for versatile transmit/receive capabilities. Naval Integration: Suitable for naval SSB radio systems with 4:1 balun and antenna coupler. Efficiency Design: Open feeder design for mast mounting with very low base capacitance for maximum efficiency. Power Handling: Safely supports 500W transmitters across the entire frequency range. We guarantee quality by producing thousands of units annually, serving domestic and international defense partners. VIEW PRODUCT DETAILS → Contact us for professional advice and technical assistance.

Military antennas are built to certain specifications, DO NOT CHANGE ANY PART OF THE ANTENNA WITHOUT ADVISING THE MANUFACTURER. Customers who want to change the color of the antenna should contact our company in advance to seek assistance with the painting procedure. Some parts of the antenna are held together with glue, and since no glue can withstand high temperatures for more than 5 minutes at 120 degrees, the glue will become brittle. It will result in the product being not waterproof. In addition, our company has another technical solution for customers that require high-temperature glue for the antenna.

Please Click here to open the FT-RF catalog! for more details about Price, Lead time, or Delivery method, please contact us!

No.  Model  Continuous High Power Handheld and Manpack Antenna Frequency (MHz) Gain (dBi) Dimensions Max Power (CW) Weight (g) Connector 1 ME-0406M02AS-NM 400-600 2 26xL566 mm 250W 600  N-Type Male 2 ME-0608M02AS-NM 600-800 2 26xL462 mm 150W 500  N-Type Male 3 ME-08M1G02S-NM 800-1000 2  26xL375 mm 150W 450  N-Type Male 4 ME-1214G05AS-NM 1200-1400 5 26xL375 mm 120W 450  N-Type Male 5 ME-1416G05AS-NM 1400-1600 5 26xL485 mm 120W 500  N-Type Male 6 ME-1618G05AS-NM 1600-1800 5 26xL406 mm 120W 500  N-Type Male 7 ME-1820G05AS-NM 1800-2000 5 26xL325 mm 120W 500  N-Type Male 8 ME-2022G05AS-NM 2000-2200 5 26xL356 mm 100W 430  N-Type Male 9 ME-2224G05AS-NM 2200-2400 5 26xL356 mm 100W 430  N-Type Male 10 ME-2426G05AS-NM 2400-2600 5 26xL346 mm 100W 410  N-Type Male 11 ME-2628G05-NM 2600-2800 5 26xL326 mm 100W 410  N-Type Male 12 ME-2830G05A-NM 2800-3000 5 26xL301 mm 75W 400  N-Type Male 13 ME-3032G05A-NM (Original: MH-3032G05A-NM) 3000-3200 5 26xL356 mm 70W 400  N-Type Male 14 ME-3234G05A-NM (Original: MH-3234G05A-NM) 3200-3400 5 26xL286 mm 70W 400  N-Type Male 15 ME-3436G05AS-NM 3400-3600 5 26xL286 mm 70W 400  N-Type Male 16 ME-3638G05AS-NM 3600-3800 5 26xL286 mm 70W 390  N-Type Male 17 ME-3840G05AS-NM 3800-4000 5 26xL286 mm 70W 390  N-Type Male 18 ME-0102M02S-NM 100-200 2 26xL900 mm 300W 500 N-Type Male  19 ME-0204M02AS-NM 200-400 2 26xL700 mm 300W 500 N-Type Male  20 ME-5060G07AS-NM 5000-6000 7 26xL500 mm 100W 400 N-Type Male  21 ME-25100MA1S-TM 25-100 1 26xL1500 mm 300W 700 N-Type Male

No. Model for Continuous High Power Antenna Freq (MHz) Gain(dbi) Size (mm) Max power (CW) Weight(Kg) Connector 1 MJ-2022G07S-NF 2000-2200 7 140xL786 120W 3.7 N-Female 2 MJ-2630G07S-NF 2600-3000 7 140xL681 120W 3.6 N-Female 3 MJ-1820G07S-NF 1800-2000 7 140xL841 120W 3.8 N-Female 4 MJ-1418G05S-NF 1400-1800 5 140xL752 150W 3.8 N-Female 5 MJ-1014G05S-NF 1000-1400 5 140xL752 150W 3.6 N-Female 6 MJ-0608M02S-NF 600-800 2 140xL681 300W 3.3 N-Female 7 MJ-0406M02S-NF 400-600 2 140xL721 300W 3.6 N-Female 8 MJ-08M1G02S-NF 800-1000 2 140xL571 200W 3.3 N-Female 9 MJ-3640G07S-NF 3640-4000 7  140xL587 100W 3.4 N-Female 10 MJ-3436G07S-NF 3000-4000 7 140xL587 100W 3.4 N-Female 11 MJ-2226G07S-NF 2200-2600 7 140xL786 120W 3.7 N-Female
