Rugged Whip Antennas (WP) | Vehicular Comms | FT-RF
- Select
HEAVY-DUTY MOBILE COMMUNICATIONS
Rugged Whip Antennas (WP)
Our Rugged Whip Antennas (WP Series) are flexible, high-durability omnidirectional antennas designed for vehicular, handheld, and field-deployed radio systems. Built with flexible fiberglass elements and high-recovery spring mechanisms, they maintain consistent RF performance through severe physical impacts and constant vibration.
*Custom length options, specific frequency tuning (VHF/UHF), and custom connector configurations are available upon request. Made in Taiwan.
⚡ Impact Resilience & RF Performance
High-Elasticity Fiberglass
Constructed with durable fiberglass components that withstand tree branch impacts and mechanical stress.
Heavy-Duty Spring Base
Integrated steel spring mechanism deflects energy on impact to protect vehicular antenna mounts and radio gear.
Wideband VHF / UHF Coverage
Provides optimal gain and low VSWR across professional communication frequency ranges.
Industrial Weatherproof Finish
Finished with matte protective coatings to resist UV exposure, saltwater corrosion, and extreme weather.
Key Applications:
| Key Parameter | Technical Specification |
|---|---|
| Radiating Element | High-Flexibility Fiberglass Construction |
| Radiation Pattern | Omnidirectional 360° Coverage |
| Impact Deflection | Integrated Heavy-Duty Steel Spring Assembly |
| Impedance Match | 50 Ω Standard Nominal Impedance |
| Connector Options | N-Male, TNC-Male, or Standard Threaded Studs |
| Environmental Grade | UV-Resistant, Corrosion-Proof & All-Weather Durable |
High Elasticity Fiberglass Impact Shock Deflection 360° Omnidirectional Gain VHF / UHF Band Coverage Industrial Matte Finish Standard Thread Connector
🛠️ Customization & Engineering Services
We provide tailored electrical tuning and mechanical customization for rugged radio whip systems:
- Custom Length & Whip Tapering: Specific length cuts tailored for targeted VHF/UHF frequencies.
- Custom Mounting Base Studs: Custom threads, magnetic bases, or heavy-duty NMO mounts.
- Industrial Coating Finishes: Non-reflective finishes in Forest Green, Desert Tan, or Stealth Black.
- Traceable VSWR Calibration: Complete test reports across required operational bands.
Direct Technical Support: info-tw@ft168.com.tw
📐 Recommended Whip Accessories
Enhance your field radio setup with compatible mounting adapters and RF assemblies:
Made in Taiwan
| Model Number: | WP-AAL600 |
| Mechanical Length: | 604 mm ± 10 |
| Net Weight: | 80 g (Ultra Lightweight) |
| Connector Type: | M8 x 1.25 - 2B |
Made in Taiwan
| Model Number: | WP-AAL700 |
| Mechanical Length: | 705 mm ± 10 |
| Net Weight: | 100 g (Lightweight) |
| Connector Type: | M8 x 1.25 - 2B |
Made in Taiwan
| Model Number: | WP-AAL700-I |
| Mechanical Length: | 705 mm ± 10 |
| Waterproofing: | Black Silicone Sealed |
| Net Weight: | 100 g (Lightweight) |
Made in Taiwan
| Model Number: | WP-AAL915 |
| Mechanical Length: | 915 mm ± 10 |
| Net Weight: | 140 g |
| Connector Type: | M8 * 1.25-2B |
Made in Taiwan
| Model Number: | WP-AAL1030 |
| Mechanical Length: | 1030 mm ± 10 |
| Net Weight: | 177 g |
| Connector Type: | M8 * 1.25-2B |
