Military VHF Wideband Discone Antenna 25 MHz to 3000 MHz N-Female
Military FT-RF Taiwan
10 out of
10
-
Description
-
Specification
-
Caution
- DC-02M03G02-NP Discone Antenna is an ultra-wideband antenna, which covers 25-3000MHz frequency bands and can be able to use with other various utility frequency bands such as amateur radio, air traffic control.
- It has a compact and lightweight design with most of the components are made of stainless steel, improving the antenna's rust resistance and endurance. Additionally, the antenna is very simple to assemble and install in any convenient location.
- It has all of the radial rods of the same length, so it can be considered as a perfect omnidirectional antenna
|
Frequency range |
25-3000MHz for receiving (50/144/430/904/1200MHz for transmitting) |
|
Heigh |
1.7m |
|
Weight |
1Kg |
|
Max. power rating |
25W (50MHz), 200W (more than 144MHz) |
|
Rated wind velocity |
40m/sec |
|
Max. diameter |
84cm |
|
Mast diameter accepted |
25mm.50mm |
|
Connector |
N-P |
|
SWR |
Less than 2.0 |
To prevent accidents, please observe the following precautions.
- Touching the antenna during transmission may cause an electric shock. When operating, make sure that there are no people around the antenna.
- Do not install near power lines, neon signs, train overhead lines, etc. Touching the antenna may cause electric shock.
- Do not touch the antenna or coaxial cable if the thunder begins. If not, you may get an electric shock.
- Select a location that is strong and steady enough to install the antenna. If not, the antenna may fall down and cause an accident.
