500MHz to 2000MHz 3dbi Vehicle Omnidirectional Jamming antenna N-Female
Military FT-RF Taiwan
10 out of
10
-
Description & Specifications
Application:
- 500MHz to 2000MHz 3dbi Vehicle Omnidirectional Jamming antenna N-Female
- Center frequency: 600 to 1000MHz
- Gain: 3dbi
- Vehicle Omnidirectional Jammer
Feature:
- Superior performance
- Lightweight
- Good appearance design
- RoHS Compliant
Electrical Specifications
| Frequency Range | 500 to 2000MHz |
| Center frequency | 600 to 1000MHz |
| V.S.W.R (MAX) | >2.0:1 |
| Antenna Type | Collinear |
| Radiation | Omnidirectional |
| Gain (peak) | 3 dBi |
| Polarization | Vertical |
| Maximum Power | 500W (CW) |
| Vertical Beamwidth (AVG) | 68 deg |
| Horizontal Beamwidth (AVG) | 360 deg |
| Impedance | 50 Ohm |
| Antenna Design | Dipole array |
| Connector | N-Female |
|
Mechanical Specifications |
|
| Size | 140xL231mm |
| Weight | 2.1 kg |
| Application | Outdoor/ Indoor |
| Radome Material | White Fiberglass |
| Mount Style | Vehicle mount |
| Parts Material | Aluminum |
| Mounting | Stainless Steel and Aluminum |
| Temperature | -40 to +120 degrees |
| Humidity | 95% |
| Waterproof | IP67 |
| Compliant with MIL | 810G |
| Vibration test | 5.0G |
| Salt spray test | 96HR |
| Color | black and green |
| Safety, Emission and other | CE, FCC, RoHS, WEEE |
