1320 MHz to 1700 MHz 3dbi Vehicle Omnidirectional Jamming GPS antenna N-Female
Military FT-RF Taiwan
10 out of
10
-
Description & Specification
Application:
- 1320 MHz to 1700 MHz 3dbi Vehicle antenna
- Vehicle mounted antenna
- Jamming Antenna
- GPS
Feature:
- Compact design, lightweight
- Superior performance
- Good appearance design
- Compliant with MIL-Std
Specification:
- Frequency: 1320 to 1700MHz
- Center frequency: 1550 to 1620MHz
- Gain: 3dbi
- MAX power: 300W (CW)
- -3db vertical polarization:68deg
- -3db horizontal polarization: 360deg
- Antenna size: 140xH249mm
- Antenna weight: 1.1kg
- Temperature: -40 to +120 degrees
- Humidity: 95%
- Waterproof: IP67
- Compliant with MIL: 810G
- Vibration test: 5.0G
- Salt spray test: 96HR
- Color: black and green
- VSWR:>2.0
