600 MHz to 800 MHz 3dbi Jamming Antenna For Vehicles BNC-Female
Military FT-RF Taiwan
10 out of
10
-
Description & Specification
Application:
- 600 MHz to 800 MHz 3dbi
- Vehicle mounted antenna
- Jamming Antenna
Feature:
- Compact design, lightweight
- Superior performance
- Good appearance design
- Compliant with MIL: 810G
Specification:
- Frequency range: 800 MHz to 1GHz
- VSWR: >2.5
- Gain: -~1dbi to 3dbi
- MAX power: 300W
- Color: black/green
- Installation size: 114.3 * M10x4
- Connector: BNC-Female
- weight : 2.8kg
- Length: 140x450mm
- -3db beamwidth: H:360 V:48
