800MHz to 1GHz High Power 8dbi Panel Directional Antenna SMA-Female
Military FT-RF Taiwan
10 out of
10
-
Description & Specification
800MHz to 1GHz 8dBi High Power Panel Antenna
LTE & GSM Band | 300W Continuous Power | Compact Patch Design
The MP-08M1G08A-SF is a high-performance Log Periodic Directional Antenna engineered for wide-spectrum VHF dominance. Delivering a stable 7 dBi gain across the 80-300 MHz spectrum, this antenna is optimized for Signal Defense and advanced protective operations. Its robust aluminum construction ensures high-degree structural integrity and mechanical survival in extreme environments.
Technical Specifications
Electrical Performance
| Frequency Range | 800 MHz to 1000 MHz |
| Gain | 8 dBi |
| Horizontal Beamwidth | 58° |
| Vertical Beamwidth | 46° |
| VSWR | ≤ 1.5 |
| Polarization | Linear (Vertical) |
| Connector | SMA-Female |
Mechanical & Environmental Specs
| Dimensions | 325 x 231 x 28 mm |
| Weight | 0.6 kg |
| Material | High-Grade Aluminum & UV-Stable Radome |
| Operating Temp | -40°C to +85°C |
Tactical Features
High-Power 300W Capacity
Engineered for continuous 300W power input, ideal for high-traffic mobile base stations or Signal Security.
800-1000 MHz Optimization
Specifically tuned for GSM 900 and LTE low-band frequencies with high efficiency.
Precise Directional Gain
8 dBi directional gain focuses signals to extend range and reduce multi-path interference.
Low-Profile Tactical Design
Minimal 28mm profile and low wind load, essential for rapid tactical deployments. Made in Taiwan.
Get a Quote / Customization
Contact us for alternative connector types, high-power requirements, or specific mounting solutions for your mobile platforms.
