50MHz to 100MHz Professional Log-periodic antenna N-Female
Military FT-RF Taiwan
10 out of
10
-
Description & Specification
50MHz to 100MHz Professional Log-Periodic N-Female Antenna
50-100 MHz High-Performance VHF Low-Band | 6 dBi Directional Gain | Made in Taiwan
The MT-L05M10G06A-NF is a high-performance Log Periodic Directional Antenna engineered for wide-spectrum VHF dominance. Delivering a stable 7 dBi gain across the 80-300 MHz spectrum, this antenna is optimized for Signal Defense and advanced protective operations. Its robust aluminum construction ensures high-degree structural integrity and mechanical survival in extreme environments.
Technical Specifications
Electrical Performance
| Frequency Range | 50 MHz to 100 MHz |
| Gain | 6 dBi |
| Horizontal Beamwidth | 110° |
| Vertical Beamwidth | 96° |
| VSWR | ≤ 1.5 |
| Polarization | Linear (Vertical or Horizontal) |
| Connector | N-Female |
Mechanical & Environmental Specs
| Dimensions | 3600 x 3600 x 300 mm |
| Weight | 13.0 kg |
| Material | High-Grade Aluminum Alloy |
| Operating Temp | -40°C to +85°C |
Key Tactical Features
VHF Low-Band Coverage
Specifically engineered for 50-100 MHz, covering tactical VHF frequencies and amateur bands with consistent performance.
Professional Log-Array
The log-periodic design ensures low VSWR and constant gain across the band, providing superior broadband efficiency.
Tactical Sector Coverage
The 110° wide horizontal beamwidth provides excellent directional coverage for sectorial monitoring and communication.
Lightweight Robust Design
Despite its large 3.6m aperture, the 13kg weight allows for versatile mounting on standard tactical masts and towers.
Get a Quote / Customization
Contact us for wind-load analysis or specialized mounting hardware for this large-scale VHF log-periodic antenna.
